CMS50D+ Pulse Oximeter

Contec

CMS50D+ Pulse Oximeter

Major Features

■ Integrated with SpO2 probe and processing display module
■ Small in volume、light in weight and convenient in carrying
■ Operation of the product is simple ,low power consumption
■ Operation menu for the function setting
■ SpO2 value display
■ Pulse rate value display, bar graph display
■ Pulse waveform display
■ The display mode can be changed
■ A pulse rate sound indication
■ With measured data overruns limits and low-voltage alarm function, the upper/down alarm range is adjustable
■ Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage, and with alarm function
■ With SpO2 value and pulse rate value of storage, the storage data can be uploaded to computers
■ Real-time data can be transmitted to computers
■ Automatically power off function: when the device is under the state of measuring interface . it will automatically power off within 5 seconds if the finger falls out of probe
■ RF Wireless communication function(Option)
■ Connected with an external oximeter probe(Option)

Main performance

Display Mode: 0.96" Dual color OLED display
Screen Resolution: 128*64
SpO2 Measuring Range: 0%～100%, (the resolution is 1%).
Accuracy: 70%～100%: ±2% ,Below 70% unspecified.
PR Measuring Range: 30bpm～250bpm, (the resolution is 1bpm)
Accuracy: ±2bpm or ±2% (select larger)
Measurement Performance in Weak Filling Condition:
SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
Resistance to Surrounding Light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
Power Consumption: less than 80mA
Voltage: DC 3.0V
Power Supply: 1.5V (AAA size) alkaline batteries × 2
Battery Working Hour: The minimum continually work time is 24 hours , theoretical number is 32 hours.
Safety Type: Interior Battery, BF Type

Accessories

Sell in standard:

■ A hanging rope
■ A user manual
■ A data line
■ A disk (PC software)
Sell in addition:
■ RF wireless module
■ Oximeter probe(Refer to probe application instruction for details and notice renewal)

Physical Identity
Dimension: 58.5(L) × 31(W) × 32 (H) mm
Weight: About 52g (with the batteries)

Qualification

Passed CE
