CMS50A Pulse Oximeter

Contec

CMS50A Pulse Oximeter

Major Features

■ Integrated with SpO2 probe and processing display module
■ Small in volume、light in weight and convenient in carrying
■ Operation of the product is simple , low power consumption
■ SpO2 value display
■ Pulse rate value display, bar graph display
■ Pulse waveform display
■ Battery capacity indication
■ With backlight
■ Automatically power off function: when the device is under the state of measuring interface . it will automatically power
off within 5 seconds if the finger falls out of probe

Main performance

Display Mode: 1.3" LCD display
Screen Resolution: 128*64
SpO2 Measuring Range: 0%～100%, (the resolution is 1%).
Accuracy:70%～100%: ±2% , Below 70% unspecified.
PR Measuring Range: 30bpm～250bpm, (the resolution is 1bpm)
Accuracy: ±2bpm or ±2% (select larger)
Measurement Performance in Weak Filling Condition:
SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
Resistance to Surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
Power Consumption:Smaller than 40mA.
Voltage: DC 3.0V
Power Supply: 1.5V (AAA size) alkaline batteries × 2
Battery Working Hour: The minimum continually work time is 15 hours , theoretical number is 28 hours.
Safety Type: Interior Battery, BF Type

Accessories

Sell in standard:

■ A hanging rope
■ A user manual

Physical Identity
Dimension: 65(L) × 35(W) × 40 (H) mm
Weight: About 75g (with the batteries)

Qualification
Passed CE
