SP-800 Infusion Pump

Features

Technical Specification

■ Bolus: 600ml/h

■ Flow rate range: 1-600ml/h

■ Volume limit: 1-9999 ml

■ Accuracy:±5％

■ KVO flow rate:1ml/h, keep vein open KVO rate

■ Power supply: AC100-240V, 50/60 Hz, 25VA

■ Water Proof: IP *I

■ Battery: Rechargeable lithium polymer battery,7.4 V，1650mAh

■ Electrical safety: compliance with the requirements of IEC 60601-1.

■ Max. Power consummation: 25W

■ Battery recharge: When the pump is connected to the AC power, the battery will automatically recharge About 8-14 hours to recharge fully Can run for more than 5 hours continuously after fully recharged.

■ Fuse Type:220V 2A*2，12V 2A*2

■ Display or information: Flow rate, volume limit, accumulated volume, power indicator light, bed No., air, occlusion, empty.

■ Alarm function: Infusion completion, occlusion, air bubble, low battery, control abnormal, no AC power supply, installation error.

■ Max. size of outer shell:120*140*190 mm-length* width* height

■ Max. weight:＜2.5 kg

■ Classification: Type B.

■ Outer shell material: ABS plastic

■ operating condition: Environment Environment temperature:+5℃- +40℃,atmosphere pressure 50-106kPa,related humidity 30%-90%

■ Storage and transport condition: Environment temperature -15℃- +50℃，atmosphere pressure 50-106kPa，relative humidity 30%-90%.

■ Applicable infusion pipe: All standard infusion pipe use "double dove" to test

■ EMC: Complies with IEC/EN60601-1-2 and IEC/EN60601-2-24.
