ECG-100G Digital Single Channel ECG

Contec

EKG

ECG-100G Digital Single Channel ECG

Features

■ High-resolution thermal printing array system

■ Frequency response is as high as 150Hz
■ Capable of printing continuously on channel trace and annotations including lead mark and parameter such as sensitivity, paper speed and filter operation status

■ High resolution digital filter inhibits baseline drift without affecting ECG waveform

■ One-touch operation

■ Concept of floating input circuit meets IEC safety standard

■ Rechargeable battery supporting more than 50 patient examinations

■ Lead Standard: 12 leads

Specifications

Input Circuit Floating; Protection against Defibrillator effect

Lead Standard 12 Leads, Lead change automatically

Patient Current Leakage <10μA

Input Impedance ≥10ΜΩ

Calibrating Voltage 1mV±3%

A/D Conversion 12 bit

Frequency Response 0.05Hz~150Hz (IEC)

Time Constant >3.2seconds

CMRR >80dB

>100dB (with filter)

EMG Filter 35Hz (-3dB) / 25Hz (-3dB)

Sensitivity 1/2, 1, 2 (cm/mV), Conversion Deviation≤5%

Recording System Thermal-array

8 dots/mm ( vertical )

16 dots/mm ( horizontal, 25mm/sec )

Paper Speed 25, 50mm/s±3%

Recording Paper 50mm,20m, high-speed roll

Input Circuit Current ≤50nA

Safety Standard IEC class I, type CF

Power Supply AC: 220V / 110V, 50/60Hz

DC: 12V rechargeable battery

Skin Voltage Tolerance ±300mV

Noise Level <15uVp-p

Dimensions 310mm×230mm×70mm

Dimension of Packing 400mm×280mm×160mm

Weight 2.75kg
