Contec
CMS50D+ Pulse Oximeter
Major Features
■ Integrated with SpO2 probe and processing display module
■ Small
in volume、light in weight and convenient in carrying
■ Operation of the product is
simple ,low power consumption
■ Operation menu for the function setting
■ SpO2 value
display
■ Pulse rate value display, bar graph display
■ Pulse waveform display
■ The
display mode can be changed
■ A pulse rate sound indication
■ With measured data
overruns limits and low-voltage alarm function, the upper/down alarm range is adjustable
■
Low-voltage indication: low-voltage indicator appears before working abnormally
which is due to low-voltage, and with alarm function
■ With SpO2 value and pulse
rate value of storage, the storage data can be uploaded to computers
■ Real-time
data can be transmitted to computers
■ Automatically power off function: when the
device is under the state of measuring interface . it will automatically power off
within 5 seconds if the finger falls out of probe
■ RF Wireless communication function(Option)
■
Connected with an external oximeter probe(Option)
Main performance
Display Mode: 0.96" Dual color OLED display
Screen Resolution: 128*64
SpO2
Measuring Range: 0%～100%, (the resolution is 1%).
Accuracy: 70%～100%: ±2% ,Below 70%
unspecified.
PR Measuring Range: 30bpm～250bpm, (the resolution is 1bpm)
Accuracy: ±2bpm
or ±2% (select larger)
Measurement Performance in Weak Filling Condition:
SpO2 and
pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is
±4%, pulse rate error is ±2 bpm or ±2% (select larger).
Resistance to Surrounding
Light: The deviation between the value measured in the condition of man-made light
or indoor natural light and that of darkroom is less than ±1%.
Power Consumption:
less than 80mA
Voltage: DC 3.0V
Power Supply: 1.5V (AAA size) alkaline batteries ×
2
Battery Working Hour: The minimum continually work time is 24 hours , theoretical
number is 32 hours.
Safety Type: Interior Battery, BF Type
Accessories
Sell in standard:
■ A hanging rope
■ A user manual
■ A data line
■ A disk (PC software)
Sell in addition:
■
RF wireless module
■ Oximeter probe(Refer to probe application instruction for details
and notice renewal)
Physical Identity
Dimension: 58.5(L) × 31(W) × 32 (H) mm
Weight: About 52g (with the
batteries)
Qualification
Passed CE
