CMS50DL Pulse Oximeter







Major Features

■  Integrated with SpO2 probe and processing display module
■  Small in volume、light in weight and convenient in carrying
■  Operation of the product is simple ,low power consumption
■  Operation menu for the function setting
■  SpO
2 value display
■  Pulse rate value display, bar graph display
■  Pulse waveform display
■  The display mode can be changed
■  Screen brightness can be changed
■  A pulse rate sound indication
■  With measured data overruns limits and low-voltage alarm function, the upper/down alarm range is adjustable
■  Battery capacity indication
■  Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage, and with alarm function
■  With SpO
2 value and pulse rate value of storage, the storage data can be uploaded to computers
■  Real-time data can be transmitted to computers
■  Automatically power off function: when the device is under the state of measuring interface . it will automatically power off within 5 seconds if the finger falls out of probe
■  Wireless communication(CMS50EW)
■  RF Wireless communication function(Option)(Only applied for Ver6.6R or above)
■  Connected with an external oximeter probe(Option)(CMS50EW, only applied for Ver6.6R or above of CMS50E)





Main performance

Display Mode: 1.3" 65K Color OLED display
Screen Resolution: 128*96
SpO
2 Measuring Range: 0%~100%, (the resolution is 1%).
Accuracy: 70%~100%: ±2% ,Below 70% unspecified.
PR Measuring Range: 30bpm~250bpm, (the resolution is 1bpm)
Accuracy: ±2bpm or ±2% (select larger)
Measurement Performance in Weak Filling Condition:
SpO
2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
Resistance to Surrounding Light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
Power Consumption: less than 100mA
Voltage: DC 3.6V~4.2V
Power Supply: Voltage 3.7 rechargeable lithium battery × 1
Battery Working Hour: 20 hours
Battery working life: Charge and discharge no less than 500 times.
Safety Type: Interior Battery, BF Type





Accessories

Sell in standard:


■  A hanging rope
■  A user manual
■  A data line
■  A disk (PC software)
■  A power adapter(GTM41076-0605;CMS0105)
Sell in addition:
■  Oximeter probe(Refer to probe application instruction for details and notice renewal)
■  RF wireless module(Only applied for Ver6.6R or above of CMS50E)

Physical Identity
Dimension: 57(L) × 32(W) × 30 (H) mm
Weight: About 50g (with the lithium battery*1)





Qualification

CMS50E passed FDA and CE
